Molded & Overmolded Components
Electrical Molded Parts
Precision Injection Molding for High-Performance Electrical Applications
The Impermeable Shield for High-Performance Power
Engineered from high-dielectric polymers, our custom-molded components provide the unbreakable moisture, thermal, and mechanical protection required.
Manufacturing Process
This process delivers precision-molded components with high dielectric strength and mechanical reliability. The process of creating electrical molded parts at PML follows a robust, quality-controlled sequence:
1
Mold Design
Custom molds developed to support complex geometries and insert placement
2
Material Selection
Selection of insulating and, where applicable, conductive materials
3
Insert Placement
Metal inserts placed in-mold for components requiring conductivity
4
Injection Molding
Molten polymer is injected to encapsulate inserts and form the part
5
Cooling
Controlled cooling ensures material integrity and dimensional accuracy
6
Ejection
The solidified part is removed from the mold
7
Post-Processing
Includes trimming, deburring, and quality inspection
Tooling Used
Technical Specification
These tools are critical for repeatability, integration, and quality in molding electrical components.
| Tool Type | Function |
|---|---|
| Custom Molds | Shape and hold inserts during injection molding |
| Insert Holders | Secure placement of connectors and terminals |
| Injection Mold Cavities | Create complex geometries around inserts |
| Ejection Systems | Remove parts post-cooling with minimal deformation |
| Thermal Regulation Units | Maintain optimal flow and curing conditions |
Forged for High-Integrity Environmental Resilience
At PML India, we specialize in developing molded electrical components with tight tolerances, reliable insulation, and long-term durability for demanding use in automotive, industrial, and consumer electronics sectors.
Inspection & Testing
All electrical molded parts undergo rigorous testing to ensure compliance with industry standards:
1
Visual Inspection
Surface quality, insert placement, and molding accuracy
2
Dimensional Measurement
Conformance to design tolerances
3
Electrical Testing
Includes continuity, insulation resistance, and contact resistance
4
Dielectric Strength Test
Assesses insulation integrity under high voltage
5
Mechanical Testing
Evaluates impact strength and wear resistance
6
Thermal Testing
Simulates high-temperature operating conditions
Key Features & Benefits
PML manufactures high-quality electrical molded components that combine functionality, safety, and precision.
1
Electrical Insulation
Protects circuits and users by preventing short circuits and electrical shocks.
2
High Durability
Withstands mechanical stress, heat, and environmental exposure.
3
Design Flexibility
Enables complex geometries, multi-material integration, and embedded inserts.
4
Customizable Configurations
Adaptable to specific voltage, current, and insulation requirements.
5
High-Performance Compliance
Meets stringent electrical safety and thermal performance standards.
Applications
Electrical molded parts manufactured by PML are widely used in:
1
Power Distribution
Circuit breakers, relays, fuse holders
2
Automotive
Sensors, connectors, electrical housings
3
Consumer Electronics
Wire organizers, switch casings, protective enclosures
4
Industrial Equipment
Terminal housings, isolators, molded cable ends
5
Telecommunication Devices
Signal connectors and junctions
Trust Reliability & Quality
With over 65 years of manufacturing excellence, PML delivers Electrical Molded Parts trusted by OEMs and Tier 1 suppliers across sectors demanding robust performance.
ISO 45001
Occupational Health and Safety (OH&S) management systems
ISO 14001
Environmental Management Systems (EMS)
ISO 9001
Quality Management Systems (QMS)
IATF 16949
International Standard for Automotive Management Systems
AS 9100
Aerospace Quality Management System (QMS)
