IoT Enabled Systems
Remote Monitoring and Control with Real-Time Sensor Feedback
Seamless Data Access from Anywhere
Empowering intelligent remote monitoring and control across diverse environments.
Global IoT System for Industrial Monitoring
This all-in-one module uses an ESP32 and cellular network to collect sensor data and send it directly to your private server.
Technical Requirements
Power Input
5V / 2A (USB-C or header pin)
Battery Backup
Integrated Li-ion with auto-charging and level indicator
Connectivity
SIM-enabled (requires active data plan)
Server Requirement
Private server for data storage and retrieval
Module Core
ESP32 + SIM800L
Key Features
1
Multi-Sensor Integration for Advanced Monitoring
This compact module supports transmission of data from up to five or six sensors, including: Temperature Sensor, Humidity/Moisture Sensor, Wind, Speed Sensor, Current Sensor, Battery Level Indicator
2
Real-Time Alerts and Control Capability
Beyond passive monitoring, the module also enables two-way communication. In critical situations, such as detecting dangerously high wind speeds in a remote wind turbine, the system can notify users and accept remote shutdown commands, preventing potential mechanical damage.
3
Flexible Power and Communication Options
Power Supply: 5V / 2A DC input: Powered via USB Type-C adapter or Li-ion battery pack with onboard charging and level monitoring.
4
Data Transmission
Operates on a 2G cellular network using a SIM card with a data plan (SIM800L-based). Ideal for small, periodic data packets.
5
Customizable Transmission Rate
Users can define update intervals for each sensor
Applications
Ideal for Remote and Autonomous Applications
1
Smart Agriculture
Soil and weather data collection for precision irrigation and crop planning.
2
Infrastructure Monitoring
Battery status, load current, and environmental conditions of remote assets.
3
Energy Management
Wind turbine control, solar monitoring, and grid-independent operations.
4
Environmental Sensing
Scalable solution for air quality, humidity, and weather tracking.
5
Automotive monitoring
Automotive-grade design support through partnerships
Frequently Asked Questions
Yes, the system supports two-way communication, allowing both data retrieval and remote commands for control actions.
